13.7W BLEDEM-CP Series Constant-Power Emergency LED Driver by Mule

The BLEDEM-CP is a UL Classified LED emergency driver that allows the same LED fixture to be used for both normal and emergency operation. In the event of a power failure, the BLEDEM-CP switches to the emergency mode and operates the existing fixture for 90 minutes. The unit contains a battery, charger, and converter circuit in a single can and will provide constant power output to the load during emergency operation. The Constant Power design of the BLEDEM-CP maintains the output wattage to the LED array even as the system voltage diminishes.

•  Universal 120-277V, 50/60 Hz input.
• Charge/Power “ON” LED Indicator light and push-to-test switch for mandated code compliance testing.
• Long-life, maintenance free, rechargeable NiCad battery.
• Output short/overcurrent protection: Electronic limiting, with normal operation resuming upon removal of fault.
• 90 Minute minimum emergency operating time over full temperature range (other run times available upon request).
• Output classification: Class 2 Compliant (excludes -MV/-HV models).
• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in a black finish.
• 5-year warranty

Model No.: BLEDEM-CP-2000
