600W X-Series Multi-Tap Magnetic Dimmable Constant Voltage Driver by Magnitude
$287.53
- X-Series Constant Voltage Magnetic LED Driver
- Single-Channel 12 or 24VAC Output
- Integrated Junction Box with Multiple ⅞“ Knock-Outs
- Multi-Tap
- Phase Dimmable with Leading (Forward) Edge MLV TRIAC Dimmer Only
- 120VAC, 50/60Hz
- Conforms to UL8750, C22.2 NO. 223
- ETL and CSA Listed
- 5-Year Warranty
SKU :
X600SOD
Brand :
Magnitude
Max Wattage :
600W
Input Voltage Range :
120V
Output Voltage :
12V | 24V
Current Range :
50, 000mA (12V) | 25, 000mA (24V)
Default Current :
50, 000mA (12V) | 25, 000mA (24V)
Dimmable :
Leading Edge, MLV, TRIAC
Dimming Range :
Not Available
Dimensions (L x W x H) :
9.43" x 4.69" x 4.25"
