60W 12V Dimmable Constant Current LED Driver by Mean Well

LPF-60D series is a 60W AC/DC LED driver featuring the constant current output. LPF-60D operates from 90~305VAC and offers models with different rated voltage ranging between 12V and 54V. Thanks to the high efficiency up to 90%, with the fan-less design, the entire series is able to operate for -40℃ ~ +80℃ case temperature under free air convection. The entire series is rated with IP67 ingress protection level and is suitable to work for a variety of applications at dry, damp or wet locations. LPF-60D is equipped with the 3 in 1 dimming function so as to provide the design flexibility for LED lighting system.

• Constant Current mode output
• Plastic housing with Class II design
• Built-in active PFC unit
• Class 2 power unit
• IP67 rating for indoor or outdoor installations
• Function: 3 in 1 dimming
• Typical lifetime > 50000 hours
• 5 years warranty
