KTLD-100-UV-SC3000-56-VDIM-U4 100W Constant Current Programmable LED Driver by Keystone

Keystone’s programmable SmartCurrent LED drivers feature multiple wattage options, from 12W to 100W. To set output current, simply program via user-friendly software to adjust the parameters and meet application needs. SmartCurrent features a dim-to-off mode, enabling dimming to 1%, for precise tuning of output current. The drivers also feature a 12Vdc/ 200mA max auxiliary power output.

• Programmable ouput current via Keystone supplied programming jig
• Dimmable with 0 –10V dimmer (down to 1% at max. output current)
• Minimum dimming level (1%, 3%, 5%, 7%, or 10%)
• Dimming curve (linear, log, inverse log, or square-law wide range of applications)
• Short circuit overload and open load protection
• Auxiliary power: 12Vdc; 200mA max (not included on the 12W and 20W models)
• UL Class P
