USCI-100140GA USCI PRO Series Constant Current LED Driver by Delta Electronics

Delta LED drivers come in different series to suit different application needs. The USCI-PRO series features program output current level. All the models come in metal casing and major international safety certifications. USCI-PRO series offers the capability to achieve different level of LED brightness via built-in 0-10V dimming function to meet various application and energy optimization needs.

• Constant current design
• Universal AC input voltage from 108-305Vac
• High efficiency up to 94%
• Wide operating temperature range -40oC ~ +55oC
• Built-in Active PFC and conforms to harmonic current IEC/EN 61000-3-2, Class C
• Adjustable constant current level through program tool
• Common mode 6kV and differential mode 6kV surge immunity
• Suitable for Dry / Damp location
• 5 years warranty
• UL LISTED, Class P & Type HL

Model No. USCI-100140GA
