XLC-25-H-KNS Multiple Stage Constant Power LED Driver by Mean Well

XLC-25-KN series is a 25W with constant power output LED driver. It can operate from 100-305V AC and output current ranging between 300mA to 1050mA selectable by ETS database. The integrated KNX interface avoids using the complicated KNX-DALI gateway. Thanks to high efficiency up to 88%, it is able to operate for -25ºC~85ºC case temperature under free air convection. XLC-25-KN series is designed based on latest safety regulations, and provides more flexibility for LED lighting application.

• Constant power mode output with multiple stage selectable by ETS database
• Plastic housing with Class II and PFC design
• Flicker-free, complying with CE ErP directive
• Standby power consumption <0.5W
• Meet emergency lighting (EL) application
• KNX/EIB protocol, support KNX data secure
• Minimum dimming level 0.5%
• 5 years warranty
