XLN-60-H-DA2 Multiple Stage Constant Voltage LED Driver by Mean Well

XLN-60 series is a 60W with constant power and constant voltage output LED driver. It can operate from 100-305V AC and output current ranging between 900mA to 1700mA selectable by dip switch or NFC setting. Thanks to high efficiency up to 90%, it is able to operate for -25ºC~90ºC case temperature under free air convection. XLC-60 series is designed based on latest safety regulations with 3-in-1 and DALI-2 dimming. XLN-60 can also be adjusted for brightness with a push button as a simple way dimming, so it provides more flexibility for LED lighting application

• Constant power mode output with multiple stage selectable by dip switch NFC setting (H-type)
• Constant voltage mode output (12/24/48V)
• Plastic housing with Class II and PFC design
• Meet UL 8750 Class 2/Class P power unit
• Flicker-free, complying with CE ErP directive
• Standby power consumption <0.5W
• Meet emergency lighting (EL) application
• 5 years warranty
